The Forge as a Joinery Shop

Traditional blacksmithing is often remembered for its dramatic shapes—scrolls, twists, and spearpoints—but the real craft lies in how pieces are connected. Before electric welding became commonplace, smiths relied on mechanical joinery: mortise and tenon joints, collars, and wedges. These methods don't just hold metal together; they create structures that can flex, be repaired, and last for centuries. A gate hung on a well-fitted tenon will still swing true long after a welded joint has cracked. The secret is understanding how hot metal moves, shrinks, and locks.

Mortise and Tenon: The Cornerstone of Forged Frames

The mortise and tenon is the workhorse of traditional metalwork. One bar carries a rectangular hole—the mortise—while the other is shouldered down to a matching tenon. The fit is deliberately tight, often with the tenon slightly smaller than the mortise so it can be drifted to a perfect interference fit.

To cut a mortise, heat the bar to a bright orange (around 1,200°C) and punch a slot slightly smaller than the finished size. Then drift it open with a series of tapered drifts, working from both sides to keep the hole central. For a tenon, heat the end of the mating bar and shoulder it down using a monkey tool—a square-ended punch that creates a clean, flat shoulder. The tenon should be long enough to protrude through the mortise by at least its own thickness.

When assembled hot, the tenon is peened over or wedged. As it cools, it shrinks, clamping the joint tight. A 16mm square bar might carry a 12mm tenon, with 2mm allowed for drifting. This joint excels in gate frames, railing panels, and truss work because the shoulder bears the load, not the pin.

Collars: Wrapping Strength Around a Joint

A collar is a band of metal wrapped around two or more bars to bind them together. Unlike a weld, a collar spreads stress over a wider area and can be replaced if damaged. Collars are common in architectural ironwork—think of the decorative bands on a park bench or the crossed bars of a window grille.

To make a collar, measure the circumference of the joint and add 10mm for shrinkage and overlap. Forge a length of 6mm round bar or 10mm x 3mm flat bar to a bright yellow heat. Wrap it tightly around the joint using a pair of tongs and a bending fork, then close the ends with a lap weld or a rivet. If forge welding, flux with borax and bring the ends to a welding heat (around 1,300°C) before hammering together. Let it cool slowly in air—never quench, as that makes the collar brittle.

Collars can also be used in combination with mortise and tenon joints, adding a belt-and-braces security that looks traditional and performs beautifully.

Wedges: The Simple Lock That Holds

Wedges are the quiet heroes of metal joinery. A tapered piece of mild steel, driven through a slot in a tenon or collar, locks the joint by friction and then by clinching. The taper is usually 1 in 10 to 1 in 20—steep enough to grip, shallow enough to drive home without splitting the surrounding metal.

For a through-tenon, cut a slot in the protruding end of the tenon with a hot set. Drive a wedge (heated to a dull red) through the slot, then bend the protruding end over with a hammer or split it and spread the halves. This prevents the wedge from backing out. In heavier work, such as bridge railings, two wedges can be driven from opposite sides at right angles—a cross wedge—for an almost immovable connection.

Wedges are also used in toolmaking: a hammer head is wedged onto its handle, and an anvil may be wedged into its stump. The principle is always the same: a small taper creates a huge locking force.

Fitting and Finishing: Making the Joint Last

Good joinery starts with clean metal. Remove scale and rust before fitting, and always test-assemble cold before the final hot fit. Allow for contraction: a joint that is tight when hot will be even tighter when cold, but too tight and you risk cracking the mortise.

Heat control is everything. Forge at the right temperature—too cold and the metal tears, too hot and it burns. Use a monkey tool for shoulders, a hot set for slots, and a drift for mortises. When driving wedges, work from both sides to avoid distortion. After assembly, brush off flux and scale, then oil or paint the joint to keep moisture out.

These techniques are not just nostalgia. They are practical, repairable, and remarkably strong. A well-cut mortise and a snug wedge will outlast the smith who made them—and that is the finest compliment a craftsperson can earn.
